Technical specifications
New from Steelboy: the Zyro Series Rotary Tiller carries a high blade count for an extra-fine seedbed in fewer passes. Multi-speed gearbox, 5.5 to 7 ft working widths for 35–55 HP tractors.
| Model | Working width (cm) | Gear box | Crown-pinion | Blades | Tractor HP | Side gear | Weight* |
|---|---|---|---|---|---|---|---|
| SR548 – 5.5 ft | 165 | Multi | — | 48 L/C | 35–40 | 20:35:28 | 420 kg |
| SR654 – 6 ft | 175 | Multi | — | 54 L/C | 40–45 | 20:35:28 | 440 kg |
| SR760 – 7 ft | 200 | Multi | — | 60 L/C | 50–55 | 20:35:28 | 480 kg |
Common to all models: dual cone mechanical oil seal · powder coated · side gear 20:35:28.
All specifications are subject to change without prior notice. Weights approximate, without PTO shaft.
